DTF Printer 24 Inch

short description:

ER-DTF300PRO Printer with 2 Epson I1600-A1s: Revolutionizing DTF Printing

introduce:

In recent years, direct film (DTF) printing has become a popular method for creating high-quality, vibrant designs on a variety of fabrics. As the demand for DTF printers continues to rise, one name stands out in the industry – ER-DTF300PRO with 2 Epson I1600-A1s. This revolutionary printer revolutionized the DTF printing process, delivering superior printing capabilities and unmatched efficiency.

Unlock unrivaled printing potential:

Paired with the Epson I1600-A1 printhead, the ER-DTF300PRO printer has demonstrated exceptional precision, reliability and speed. Equipped with advanced micro piezo inkjet technology, the printer ensures that every image, pattern or design is reproduced with exceptional clarity, color vibrancy and accuracy. By utilizing multiple print heads, it increases productivity and allows simultaneous printing on multiple garments, saving valuable time and significantly increasing throughput.


Product Detail

Product Tags

Detail-01 Detail-02 Detail-03

Model No.
ER-DTF 300PRO
Printing Speed
4pass 8-12sqm/h,
6pass 5.5-8sqm/h,
8pass 3-5sqm/h
Printer Head
2pcs Epson I1600-A1
File Format
PDF,JPG,TIFF,EPS,Postscript,etc
Max Print Size
300mm
Software
Maintop /Photoprint
Max Printing thickness
2mm
Voltage
AC-220V/110V 50Hz/60Hz
Printing Quality
True Photographic Quality
Interface
3.0 LAN
Board
Hoson
Operating System
WINDOWS 7/WINDOWS 8/WINDOWS 10
Ink System
CISS Built Inside With Ink Bottle
Power Consumption
500W
Ink Colors
CMYK+W
Package Type
Wooden Case
Ink Type
DTF pigment ink
Working Environment
20 –30Degrees.
Servo Motor
Leadshine motor
Net Weight
60kg
Ink station
drawing method
up and down
Machine Size
960*650*440mm
Printing material
Heat transfer PET fifilm
Gross Weight
80kg
Printing Method
Drop-on-demand Piezo Electric Inkjet
Package Size
1040*650*600mm

Detail-04 Detail-05 Detail-06 Detail-07 Detail-08 Detail-09

Detail-12 Detail-13 Detail-14 Detail-15 Detail-16 Detail-17 Detail-18 Detail-19
