Eco Solvent Digital Printer

short description:

Introducing the revolutionary ER-ECO 3204PRO, a cutting-edge printing solution redesigned to meet all your needs. This remarkable printer is equipped with four premium Epson I3200 E1 printheads, ensuring unrivaled performance and outstanding print results.

ER-ECO 3204PRO is designed to optimize your printing experience. With its advanced technology and precision engineering, it delivers unrivaled print quality, speed and reliability. Whether you need to print labels, posters, banners or any other graphics, this printer guarantees impressive output to captivate your audience.

The ER-ECO 3204PRO features the Epson I3200 E1 printhead, considered the industry gold standard, for superior image resolution, color accuracy and intricate detail. These printheads feature increased durability and longevity, ensuring consistent high-quality prints even during heavy-duty use. Capable of producing vibrant, true-to-life colors and crisp text, this printer sets a new standard for professional-grade printing.


Product Detail

Product Tags

Detail-01Detail-02Detail-03

Model No.
ER-ECO 3204PRO
Printing Speed
4 heads I3200 speed:
2Pass: 150 sqm/h
4Pass: 80 sqm/h
6Pass: 55 sqm/h
Printer Head
4 pcs Epson i3200 E1 Print Head
Max Media Weight 60 KG
Max Print Size
125.98” (3200mm)
Operating System WINDOWS 7/ WINDOW 10
Max Print Height 1-5mm Interface LAN
Printing Resolution
Standard Dpi: 1440*2880dpi
Software Maintop/Photoprint
Printing Quality
True Photographic Quality
Voltage AC-220V 50Hz/60Hz
Nozzle Number 3200 Working Environment 15-30 Degrees.
Ink Colors
CMYK
Power Consumption
8500W
Ink Type Eco Solvent Ink Package Type Wooden Case
Ink Supply
2.5 L ink tank with positive pressure
continous supply
Machine Size
4424*907*1530(H)mm
File Format TIFF,JPEG,EPS,PDF Net Weight
750kgs
Media Feeding System Manual Gross Weight
840kgs
Machine Type
Automatic,Roll to Roll,Digital Printer
Packing Size
4500*1000*1550(H)mm
Materials to Print
PP Paper/Backlit fifilm/Wall paperlvinyl
One-way vision/Flex banner etc

Detail-05 Detail-06 Detail-07

Detail-08Detail-12Detail-13Detail-14Detail-15Detail-16Detail-17Detail-18Detail-19
