large format 1016 uv glass leather furniture uv led printer printing machine uv flatbed printer

short description:

UV flatbed printer price main Features:

1.Japanese imported EP-DX5/DX7/XP600/TX800 heads and RH TH5241 G5i / G5 /G6 heads optional

2.CMYK white and varnish optional for glossy surface and high quality printing

3.Upgraded negative pressure system to ensure high accuracy 0.01kp difference for high quality printing performance

4.Vacuum bed to hold the flexible media like PVC, foam board, acrylic sheet etc.

5.Applications in advertising& signage industry and decoration industry

6.Can print on Glass, Metal, Ceramic Tiles, PVC, Acrylic, Leather, Plastic, Wood, etc.


Product Detail

Product Tags

Name Large format uv flatbed printer
service life of printheads 24 months
Color CMYK CMYK WW / CMYK CMYK WHITE VARNISH
Printing speed 4 pass :12m2/h
6 pass :10m2/h
8 pass :8m2/h
Pirnt resolution 4 pass :720*600dpi   6pass:720*900dpi  8pass :720*1200dpi
Machine UV1016
Print material acrylic ,alumious ,model board ,ceramic tile, metal,glass,leather ,mouse etc.
Printing height 10cm
Uv lamp with
Rip software Photoprint
Supply voltage,Power 220V
Image format TIFF
Operation environment temperature :27℃ - 35℃, humidity:40%-60%
Aviable ink UV ink
Max Printing size 100cm*160cm
USB   Data interface Lan
Board type (brand) DPCS
Rail brand HW2.0
Servo Motor Brand JMK
UV  lights 2 (without varnish ) , 4 ( with varnish )
Ink Tank 1L
Beam material aluminum
Machine size /
Packing size 2.24m*2.22m*1.55m
operation system  Windows7/window8/windows10
suction Vacuum suction platform
warranty one year

uv1016详情页_副本
