Roll-To-Roll UV Label Printer - 2022 Latest design Larger format UV2513 flatbed printer with I3200-U1 heads – Aily

short description:


Product Detail

Product Tags

Related Video

Feedback (2)

Our aim is usually to give superior quality items at aggressive rates, and top-notch company to clients around the earth. We have been ISO9001, CE, and GS certified and strictly adhere to their good quality specifications for Eco Solvent Printers Desk Top , Eco Solvent Ink L1300 , A4 Small Eco Solvent Printer , Items won certifications with the regional and international primary authorities. For far more detailed information, please contact us!
Roll-To-Roll UV Label Printer - 2022 Latest design Larger format UV2513 flatbed printer with I3200-U1 heads – Aily Detail:

Technology Parameter

Model No. Eric 2513
Printer head 3/4pc I3200-U1
Machine Type Automatic, Flatbed, UV LED Lamp, Digital Printer
Max Print Size 2500*1300mm
Max Print Height 10cm
Materials to Print Metal, Plastic, Glass, Wood, Ceramics, Acrylic, Leather, etc,
Printing Direction Unidirectional Printing or Bi-directional Printing Mode
Printing  Resolution Mode 1 :4Pass 1CMYK + 1W + 1V =3 heads ; speed 11Sqm/h
Mode 2 :4Pass 2CMYK + 2W =4 heads ; speed 19Sqm/h
Mode 3 :4Pass 4CMYK  =4heads ; speed 30Sqm/h
Nozzle Number 3200
Ink Colors CMYK+W+C
Ink Type UV Ink
Ink System 1500ml Ink Bottle
File Format PDF,JPG,TIFF,EPS,AI,etc
Max Media Weight 75 KG/M²
Operating System WINDOWS 7/WINDOWS 8/WINDOWS 10
Interface 3.0 LAN
Software Photoprint/Maintop
Languages Chinese/English
Voltage 220V
Working Environment temperature :27℃ - 35℃, humidity:40%-60%
Package Type Wooden Case
Machine size 4100*10000*1350mm

1.Hoson Board

Ensure stable and smooth operation.

cdsvfd

2.4 separate zones vacuum platform

Separate operation zone makes accurate control to the vacuum platform.

cvdv

3.Negative ink supply+capping

Making sure high speed printing and stable ink supplying.

cfvd

4.Anti-collison

This setting is protecting the printer head from hurting,so that the printer head have a longer time

cdvdfv

5.Auto height detect

cdvdfvfd

6.Ink bulk alarm system

Every color have individual ink lack alarm,to make customer easier figure out which color of ink is not enough.

cdcsg

Applications

cvdfvgfd gbdhngf


Product detail pictures:

Roll-To-Roll UV Label Printer - 2022 Latest design Larger format UV2513 flatbed printer with  I3200-U1 heads – Aily detail pictures

Roll-To-Roll UV Label Printer - 2022 Latest design Larger format UV2513 flatbed printer with  I3200-U1 heads – Aily detail pictures

Roll-To-Roll UV Label Printer - 2022 Latest design Larger format UV2513 flatbed printer with  I3200-U1 heads – Aily detail pictures
